Product Introduction

RX Engineering Inc. is
specialized in designing and
manufacturing high-temperature and
high-pressure reaction systems.

Additional functions are implemented in the standard reactor system to
create a specialized system,

Recently, we have proposed a system based on application and provided
an optimized system through consultation, maximizing customer request.

Series / Spec.	Capacity	Stirring	Designed Press.	Designed Temp.	Material	Application
PV-SERIES (Pressure Vessel)	50ml ~ 1000 Liter	X	Vacuum ~ 10,000 psi	Below Zero ~ 600℃	STS304,STS316L,HC-276 IN600/625,Ti.,Zr., etc.	hydrothermal synthesis, etc.
SR-SERIES (M) (Metal Stirred Reactor)	50ml ~ 1000 Liter	O	Vacuum ~ 10,000 psi	Below Zero ~ 600℃	STS304,STS316L,HC-276 IN600/625,Ti.,Zr., etc.	hydrothermal synthesis, Hydrogenation reaction, Supercritical reaction, Polymer synthesis reaction, Carbon series manufacturing, etc.
*SR-SERIES (G) (Glass Stirred Reactor)	50ml ~ 10 Liter	O	Vacuum ~ 150 psi	Below Zero ~ 200℃	Tempered glass, Pyrex Quartz, etc.	hydrothermal synthesis, Hydrogenation reaction, Supercritical reaction, Polymer synthesis reaction, Carbon series manufacturing, etc.
TR-SERIES (Continuous tube reactor)	50ml ~ 1000 Liter	X	Vacuum ~ 10,000 psi	Room Temperature ~ 800℃	STS304,STS316L,HC-276 IN600/625,Ti.,Zr., etc.	Catalyst Development, Catalyst evaluation, Coal gasification reaction, Reformation of residual oil, etc.
SF-SERIES (Supercritical reactor)	50ml ~ 10 Liter	X/O	Vacuum ~ 10,000 psi	Room Temperature ~ 800℃	STS304,STS316L,HC-276 IN600/625,Ti.,Zr., etc.	Oxidation, Cleaning, Spice oil, Flavoring, Air freshener, Pigments, Tea & Coffee Caffeine Extraction, Nanoparticle production, Aerogel drying, etc

* In case of Glass reactor, design pressure is changeable as condition of operation( temperature, press.).
